Load Regulation Power Efficency -> 3660A Stand-Alone Automatic Multiple Output Power Supply Tester

3660A Stand-Alone Automatic Multiple Output Power Supply Tester

AC Power 115/230Vac ± 10%
AC Source Input 115 / 230Vac
Weight: 24Kg
Dimension: 483(W) x177(H) x445(D) mm
Digital Output port: 8 Bit

Power Cord: 2 Pcs
9860A Application Software: 1 pc
Operation Manual: 1 pc

Under Order Information

3660A ATX Six Output Power Supply Tester
3660A-XX Custom 3660A
Custom load requirements for loads 2 through 6 can not exceed a combined total of 680W.
Serial numbers will be assigned according to custom specifications.
9906 Integrated Twin Test Fixture Testing Fixture Universal Test Fixture
9932: Remote Interface Key Pad (File 56START , STOP)
